Feature
1. Wet-installed submersible is wastewater equipment motor IP68. Class F,
with self – cleaning impeller Built
2. double mechanical seal.
3. Built-in leakage sensor and the alarming device for the over-temperature protection.
Application
Use for mixing agitating and making ring flows in the process of municipal and industrial sewage treatment, activated sludge tank, bioreactor tank, mixing tank, sludge silos equalizing reservoir, sewage tank and etc.
Construction
Performance parameters
Performance parameters
| Propeller | Ø1100-Ø25000 mm |
|---|---|
| Depth | ≤ 20 M (Max) |
| Power | 1.5-4 KW |
| Speed | 1400RPM, 960RPM, 740RPM, 480RPM |
| Material | Carbon Steel |
| Temp | ≤40 °C |
| PH | PH 5-9 |
